Ib qho "down lub qhov" (Dhd380 Dth Bit) me ntsis yog ib hom kev drilling cuab yeej siv nyob rau hauv ntau yam lag luam, feem ntau hauv kev tsuas, kev tsim kho, thiab kev tshawb nrhiav roj thiab roj. Nws tseem hu ua DTH rauj me ntsis. DTH drilling yog ib txoj hauv kev drilling boreholes lossis qhov dej qhov twg lub pneumatic lossis hydraulic rauj txuas rau hauv qab ntawm txoj hlua xyaum ntaus DTH ntsis, uas yog lub luag haujlwm rau kev tawg pob zeb lossis lwm yam khoom siv hauv qab.
daim ntawv thov
LEANOS
Daim ntawv thov ntawm Dhd380 Dth Bit:
Mining: DTH drilling yog dav siv hauv kev lag luam mining rau kev tshawb nrhiav, kev tsim khoom drilling, thiab blasting. DTH cov khoom yog qhov tseem ceeb hauv kev rho tawm cov pob zeb thiab cov pob zeb los ntawm cov pob zeb hauv av.
Kev tsim kho: DTH cov khoom siv rau hauv kev tsim kho qhov project rau drilling qhov hauv pob zeb thiab pob zeb rau ntau lub hom phiaj, nrog rau kev txhim kho thauj tog rau nkoj, hauv paus piling, thiab tunneling.
Dej Drilling: DTH cov khoom siv hauv cov dej zoo drilling kom nkag tau cov dej hauv av kom zoo. Lawv lub peev xwm los laum los ntawm cov pob zeb nyuaj yog qhov tseem ceeb tshwj xeeb hauv cov cheeb tsam arid.
Geothermal Drilling: DTH cov khoom ua si lub luag haujlwm tseem ceeb hauv geothermal drilling, qhov chaw uas lawv tsim cov boreholes rau kev rho tawm ntawm geothermal zog, eco-friendly thiab tauj dua tshiab zog.
Bit Shank
LEANOS
DHD Shank: DHD (Down-the-Hole) shank yog siv dav siv me ntsis shank configuration. Nws yog sib xws nrog DHD series DTH hammers thiab feem ntau yog siv rau drilling hauv ntau hom pob zeb.
SD Shank: SD (Sandvik) shank yog lwm qhov nrov me ntsis shank configuration. Nws yog sib xws nrog Sandvik's DTH rauj tshuab thiab feem ntau siv hauv kev siv tsuas thiab kev tsim kho.
QL Shank: QL (QLite) shank feem ntau txuam nrog Atlas Copco's DTH rauj tshuab. Nws yog siv rau drilling nyob rau hauv ib tug ntau yam ntawm geological tej yam kev mob thiab paub txog nws durability.
Lub Hom Phiaj Shank: Lub Hom Phiaj shank khoom yog tsim los siv nrog Lub Hom Phiaj series DTH hammers. Lawv tau siv dav hauv kev tsim kho thiab kev siv quarrying.
Numa Shank: Numa shank khoom siv nrog Numa DTH hammers. Cov khoom no paub txog lawv cov kev ua tau zoo thiab tuaj yeem ua haujlwm ntau yam kev siv drilling.
BR Shank: BR (Breakout) shank khoom siv nrog breakout-hom DTH hammers. Cov khoom no haum rau drilling hauv cov pob zeb nyuaj.
CIR Shank: CIR (Concentric Impactor) shank cov khoom siv nrog CIR-hom DTH hammers, uas feem ntau siv hauv dej zoo drilling thiab geotechnical daim ntaub ntawv.
Mach44 Shank: Mach44 shank khoom yog tsim los siv nrog Mach44 series DTH hammers. Lawv paub txog lawv qhov kev nkag siab siab.
Khoom Parameters
LEANOS
Technical Parameters Ntawm DHD380 DTH ntsis
| Txoj kab uas hla | Gauge Khawm | Pem hauv ntej khawm | Qhov hnyav (KG) | Tshooj Naj Npawb | ||||
| mm | Ntiv | Lub ntsej muag | Lub ntsej muag Convex | Concave ntsej muag | Hom ntsej muag | |||
| 203 | 8 | Φ18*10 | Φ18*8 | / | Φ16*5 | Concave ntsej muag | 47.0 | LR-DHD380-203CC |
| 216 | 8 1/2 | Φ18*10 | Φ18*8 | / | Φ16*6 | Concave ntsej muag | 51.2 | LR-DHD380-216CC |
| 219 | 8 5/8 | Φ18*10 | Φ18*8 | / | Φ16*6 | Concave ntsej muag | 51.7 | LR-DHD380-219CC |
| 229 | 9 | Φ18*12 | Φ16*12 | / | Φ16*7 | Concave ntsej muag | 53.3 | LR-DHD380-229CC |
| 235 | 9 1/4 | Φ18*12 | Φ16*12 | / | Φ16*7 | Concave ntsej muag | 54.3 | LR-DHD380-235CC |
| 245 | 9 5/8 | Φ19*12 | Φ16*12 | / | Φ16*8 | Concave ntsej muag | 58.4 | LR-DHD380-245CC |
