Khoom Description LEANOS
DHD 360 rauj yog tsim los muab kev ua haujlwm siab drilling thiab kev ntseeg siab hauv ntau yam pob zeb tsim, suav nrog cov qauv tawv thiab abrasive.
Qee yam ntawm DHD 360 rauj muaj xws li:
1. High drilling ceev: DHD 360 rauj muaj peev xwm ua tiav qhov siab drilling ceev, ua rau nws tsim nyog rau cov ntawv thov uas yuav tsum tau ceev thiab zoo drilling.
2. Durability: Lub rauj yog ua los ntawm cov ntaub ntawv zoo thiab yog tsim los tiv thaiv kev ua haujlwm siab drilling, ua rau nws yog ib qho khoom siv ruaj khov rau kev thov rau kev thov drilling.
3. Kev saib xyuas yooj yim: Lub rauj yog ib qho yooj yim rau disassemble thiab reassemble, cia kom ceev thiab yooj yim txij nkawm thiab kho.
4. Versatility: DHD 360 rauj tuaj yeem siv rau hauv ntau hom kev siv drilling, suav nrog kev tsuas, kev tsim kho, thiab qhov chaw drilling.
Qee qhov kev siv feem ntau ntawm DHD 360 rauj suav nrog:
1. Kev Mining: Lub rauj feem ntau yog siv rau hauv kev ua haujlwm mining los laum qhov blast qhov thiab rau kev tshawb nrhiav drilling.
2. Kev tsim kho: DHD 360 rauj yog siv hauv kev tsim kho xws li lub hauv paus drilling, tunneling, thiab piling.
3. Geothermal drilling: Lub rauj yog siv nyob rau hauv geothermal drilling los laum qhov tob tob rau kev sib pauv cua sov thiab kev tsim hluav taws xob.
Zuag qhia tag nrho, DHD 360 rauj yog ntau yam thiab txhim khu kev qha uas tau siv dav hauv kev lag luam drilling. Nws qhov kev ua haujlwm siab drilling, ua haujlwm ntev, thiab yooj yim ntawm kev saib xyuas ua rau nws muaj kev xaiv nrov rau ntau hom kev siv drilling.
Specification LEANOS
Nov yog qee cov khoom lag luam ntawm DHD 360 rauj:
Hom Rauj: DHD 360
Bit Shank Hom: DHD 360
Rauj Ntev: 1263mm
Rauj Nyhav: 113 kg
Sab nraud txoj kab uas hla: 148 mm
Ntsis Dia: 165-190mm
Ua Haujlwm Siab: 10-25 bar
Kev cuam tshuam tus nqi ntawm 17 Bar: 25 Hz
Pom zoo tig ceev: 25-50 rpm
Kev siv cua: 14Bar--15.8m³/min; 21bar--23.5m³/min; 24Bar--27.5m³/min
Haum Pob Zeb Hardness: F=10-20
Nco ntsoov tias cov khoom lag luam tsis tuaj yeem sib txawv nyob ntawm cov chaw tsim khoom thiab cov qauv tshwj xeeb ntawm DHD 360 rauj. Nws yog qhov zoo tshaj plaws los xa mus rau cov chaw tsim khoom cov lus qhia tshwj xeeb rau cov ntaub ntawv raug thiab hloov tshiab ntawm cov khoom.
