Khoom Description
LEANOS
A DTH Rauj 8 Nti, tseem hu ua Down-The-Hole rauj, yog lub tshuab pneumatic drilling cuab yeej siv dav hauv kev tsuas, kev tsim kho, thiab roj thiab roj kev lag luam rau drilling qhov hauv ntau hom pob zeb tsim. Qhov tshwj xeeb "8 nti" yog hais txog txoj kab uas hla ntawm lub rauj me ntsis, uas txiav txim siab qhov loj ntawm lub qhov nws tuaj yeem tsim.
DTH rauj ua haujlwm ntawm lub hauv paus ntsiab lus ntawm percussive drilling. Compressed cua yog siv los tsav lub piston hauv lub rauj, uas ntaus lub nraub qaum ntawm ib lub laum me ntsis txuas rau pem hauv ntej kawg ntawm rauj. Lub zog los ntawm cov kev cuam tshuam rov qab no ua rau lub pob zeb tawg, thiab cov khib nyiab uas tshwm sim tau raug tshem tawm los ntawm huab cua, tsim lub qhov.
Cov yam ntxwv tseem ceeb thiab cov txiaj ntsig ntawm DTH Hammer 8 Inch yuav suav nrog:
Drilling efficiency:Ib qho DTH Rauj 8 Nti yog tsim rau tsim cov kab loj dua qhov, uas tuaj yeem ua tau zoo rau ntau yam kev siv, xws li lub hauv paus drilling, quarrying, thiab qee yam kev ua haujlwm mining.
Fast Penetration:Qhov kev txiav txim siab ntawm lub rauj tso cai rau kev ua haujlwm nrawm nrawm, ua rau nws ua haujlwm zoo rau cov haujlwm uas yuav tsum tau tsim qhov nrawm nrawm.
Adaptability:DTH hammers muaj ntau yam thiab tuaj yeem siv rau hauv ntau hom pob zeb thiab hauv av, ua rau lawv nyiam xaiv rau qhov nyuaj qhov chaw drilling.
Kev tsim kho ruaj khov:DTH Hammer 8 Nti yog tsim los tiv thaiv kev cuam tshuam loj thiab muaj lub neej ua haujlwm ntev, txo qis qis vim kev saib xyuas.
Precise Control:Lub rauj qhov cuam tshuam zaus thiab lub zog tuaj yeem hloov kho, muab kev tswj hwm ntawm cov txheej txheem drilling thiab tso cai rau kev pom zoo hauv cov qauv sib txawv.
Yam tsawg kawg nkaus Deviation:DTH drilling feem ntau ua rau lub qhov ncaj dua piv rau lwm txoj kev drilling, uas yog qhov tseem ceeb rau kev siv xws li blasting thiab piling.
Txo kev vibration:Qhov kev txiav txim siab ntawm DTH Hammer 8 Inch ua rau muaj kev vibration tsawg dua piv rau lwm cov txheej txheem drilling, txo qhov kev pheej hmoo ntawm kev puas tsuaj rau cov cuab yeej thiab txo qhov cuam tshuam rau ib puag ncig ib puag ncig.
Nqi-zoo:DTH drilling feem ntau suav hais tias yog tus nqi zoo vim nws qhov siab drilling tus nqi thiab tsawg tsawg thiab tsim kua muag ntawm cov khoom siv drilling.
Thaum xav txog kev siv DTH Rauj 8 Nti, nws yog ib qho tseem ceeb uas yuav tsum tau coj mus rau hauv tus account yam xws li cov xwm txheej tshwj xeeb ntawm qhov chaw, qhov xav tau qhov loj me, thiab qhov xav tau qhov tob drilling. Kev cob qhia kom raug, kev saib xyuas, thiab kev ntsuas kev nyab xeeb yuav tsum tau ua raws li kom ntseeg tau tias kev ua haujlwm zoo thiab nyab xeeb.
Specification
LEANOS
Technical Parameters Ntawm QL80 DTH Hammers
|
Bit Shank |
qw 80 |
|
Qhov Loj |
Φ{0}} hli |
|
Kev sib txuas xov |
API 4 1/2" Reg |
|
Ua Haujlwm Siab |
10-25Bar / 1-2.5Mpa |
|
Ceev Qhia |
20-45rpm |
|
Rub Force pom zoo |
19 KN |
|
Ntev |
1 471mm |
|
Qhov hnyav |
20 3 Kg |
Technical Parameters Ntawm QL80 DTH Bits
|
Txoj kab uas hla |
Gauge Khawm |
Pem hauv ntej khawm |
Qhov hnyav (KG) |
Tshooj Naj Npawb |
||||
|
mm |
Ntiv |
Lub ntsej muag |
Lub ntsej muag Convex |
Concave ntsej muag |
Hom ntsej muag |
|||
|
203 |
8 |
Φ18*10 |
Φ18*8 |
/ |
Φ16*5 |
Concave ntsej muag |
50.1 |
LN-QL80-203CC |
|
216 |
8 1/2 |
Φ18*10 |
Φ18*8 |
/ |
Φ16*6 |
Concave ntsej muag |
54.3 |
LN-QL80-216CC |
|
219 |
8 5/8 |
Φ18*10 |
Φ18*8 |
/ |
Φ16*6 |
Concave ntsej muag |
54.8 |
LN-QL80-219CC |
|
229 |
9 |
Φ18*12 |
Φ16*12 |
/ |
Φ16*7 |
Concave ntsej muag |
56.4 |
LN-QL80-229CC |
|
235 |
9 1/4 |
Φ18*12 |
Φ16*12 |
/ |
Φ16*7 |
Concave ntsej muag |
57.4 |
LN-QL80-235CC |
|
245 |
9 5/8 |
Φ19*12 |
Φ16*12 |
/ |
Φ16*8 |
Concave ntsej muag |
61.5 |
LN-QL80-245CC |
