Khoom Description
LEANOS
Lub Hydraulic Pob Zeb DTH Rauj yog cov cuab yeej tshwj xeeb drilling siv hauv ntau qhov kev lag luam, feem ntau hauv kev tsuas, kev tsim kho, thiab kev tshawb nrhiav. Nws muaj ntau yam zoo dua lwm txoj kev drilling thiab rauj. Nov yog qee qhov zoo ntawm hydraulic pob zeb DTH rauj:
Ua kom zoo drilling: Hydraulic pob zeb DTH hammers paub txog lawv cov kev ua haujlwm siab drilling. Lawv siv kev sib xyaw ua ke ntawm cov cua kub siab thiab lub zog txhua yam kom nrawm rau rauj thiab tawg cov pob zeb tsim. Qhov kev hloov hluav taws xob zoo no tso cai rau kev nkag mus sai dua piv rau lwm txoj hauv kev drilling.
Qhov tob qhov drilling: DTH hammers yog tsim los rau qhov sib sib zog nqus qhov drilling daim ntaub ntawv. Lawv tuaj yeem ua tiav qhov tob tob thaum tswj xyuas qhov tseeb thiab tsim khoom. Qhov no ua rau lawv haum rau cov dej num xws li geotechnical drilling, dej zoo drilling, thiab tshawb nrhiav ntxhia.
Versatility: Hydraulic pob zeb DTH hammers yog sib xws nrog ntau yam drilling rigs, nrog rau crawler-mounted, tsheb-mounted, thiab hydraulic excavator-mounted rigs. Qhov no versatility tso cai rau lawv siv nyob rau hauv txawv terrains thiab ib puag ncig.
Superior qhov ncaj: DTH hammers muab qhov zoo ntawm qhov ncaj, txhais tau tias lawv tuaj yeem laum qhov tseeb thiab raug. Qhov no yog qhov tseem ceeb hauv kev siv xws li blasting, qhov twg qhov kev sib raug zoo yog qhov tsim nyog rau kev ua kom zoo ntawm pob zeb tawg.
Txo kev sib txawv: Piv rau lwm txoj kev drilling, hydraulic pob zeb DTH hammers muaj kev txo qis kev sib txawv thaum drilling. Qhov no txo qis txoj hauv kev los ntsib qhov teeb meem ntawm qhov drilling los yog ntsib kev npaj txhij txog geological formations.
Cov nqi khiav lag luam qis dua: DTH rauj muaj cov nqi khiav lag luam qis dua vim lawv cov txiaj ntsig thiab kev tsim khoom. Lawv tuaj yeem ua tiav cov haujlwm drilling hauv lub sijhawm tsawg, xav tau cov khoom siv tsawg dua thiab cov nqi kho mob qis dua.
Txhim khu kev ruaj ntseg: Hydraulic pob zeb DTH hammers muab kev ruaj ntseg zoo dua qub, xws li lub zog nyem thiab kev cuam tshuam kev nyab xeeb, tiv thaiv kev sib tsoo thiab tiv thaiv cov neeg ua haujlwm thaum lub sijhawm ua haujlwm drilling.
Ib puag ncig tus phooj ywg: DTH hammers tsim kev vibrations thiab suab nrov tsawg dua piv rau lwm txoj hauv kev drilling, ua rau muaj kev cuam tshuam tsawg dua rau ib puag ncig ib puag ncig thiab txo qhov cuam tshuam rau cov qauv nyob ze.
Zuag qhia tag nrho, qhov zoo ntawm hydraulic pob zeb DTH hammers ua rau lawv muaj kev xaiv nrov rau ntau yam kev siv drilling, muab cov kev daws teeb meem zoo, raug, thiab raug nqi zoo drilling.
Disassembling Hydraulic Pob Zeb DTH Rauj yuav tsum tau ua tib zoo tuav thiab paub txog cov qauv tshwj xeeb uas koj ua haujlwm nrog. Thaum kuv tuaj yeem muab qee qhov kev taw qhia dav dav, nws tseem ceeb heev uas yuav tsum tau xa mus rau cov chaw tsim khoom cov lus qhia thiab cov lus qhia rau koj tus qauv rauj tshwj xeeb. Nov yog qee cov kauj ruam koj tuaj yeem ua raws:
Kev ceev faj txog kev nyab xeeb: Ua ntej pib cov txheej txheem disassembly, xyuas kom meej tias koj muaj cov iav ruaj ntseg zoo, suav nrog hnab looj tes, looj tsom iav, thiab cov cuab yeej tsim nyog. Xyuas kom tseeb tias lub rauj yog depressurized thiab disconnected los ntawm tej qhov chaw fais fab.
Siv phau ntawv qhia: Tau txais cov chaw tsim khoom phau ntawv lossis cov ntaub ntawv qhia txog koj lub pob zeb hydraulic DTH rauj. Nws yuav muab cov lus qhia tshwj xeeb, daim duab kos, thiab cov npe ib feem, pab koj nkag siab txog cov txheej txheem disassembly zoo dua.
Npaj ib qho chaw ua haujlwm huv: Nrhiav thaj chaw huv thiab muaj kev sib koom ua ke uas koj tuaj yeem tshem tau rauj. Muab ib daim ntaub huv huv los sis ib lub tais kom cov khoom me me kom ruaj khov thiab tiv thaiv kom tsis txhob dov.
Txheeb xyuas thiab tshem tawm cov ntsaws ruaj ruaj: Feem ntau hydraulic pob zeb DTH hammers muaj lub taub hau pem hauv ntej thiab nraub qaum. Nrhiav thiab tshem tawm cov bolts uas ruaj ntseg rau pem hauv ntej thiab nraub qaum taub hau ua ke. Xa mus rau phau ntawv qhia txog tus naj npawb thiab qhov chaw ntawm cov bolts no.
Cais lub taub hau pem hauv ntej thiab nraub qaum: Thaum cov ntsia hlau tuav tau raug tshem tawm, ua tib zoo cais lub taub hau pem hauv ntej thiab nraub qaum. Lawv tuaj yeem txuas nrog threads, yog li maj mam unscrew lawv. Yog tias lawv tau nruj nruj, koj yuav xav tau ib lub cuab yeej tshwj xeeb xws li rauj ciaj ntswj lossis pluaj ciaj ntswj los pab cais lub taub hau.
Tshem lub piston: Hauv lub rauj, koj yuav pom lub piston. Nyob ntawm tus qauv tsim, nws tuaj yeem ruaj ntseg los ntawm cov bolts ntxiv lossis tus pin tuav. Xa mus rau phau ntawv qhia txog txoj kev tshwj xeeb kom tshem tawm lub piston.
Disassemble cov khoom seem: Tom qab tshem lub piston, txuas ntxiv disassemble cov khoom seem, xws li chuck, hnav lub tes tsho, O-rings, thiab lwm yam. Ua raws li cov lus qhia hauv phau ntawv qhia kom paub tseeb tias koj disassemble lawv kom raug thiab tsis txhob ua kom puas tsuaj.
Tshawb xyuas thiab ntxuav: Thaum koj disassemble lub pob zeb hydraulic DTH rauj, ua tib zoo tshuaj xyuas txhua yam ntawm cov cim ntawm kev hnav, kev puas tsuaj, lossis kev tsim. Ntxuav cov khoom uas siv cov tshuaj ntxuav kom tsim nyog thiab tshem tawm cov khib nyiab lossis cov kab mob uas yuav cuam tshuam rau rauj kev ua haujlwm.
Hloov cov khoom hnav lossis puas lawm: Yog tias koj txheeb xyuas cov khoom hnav lossis puas tsuaj thaum lub sijhawm kuaj xyuas, sab laj nrog tus kws tsim khoom cov lus qhia rau kev hloov cov khoom thiab tau txais cov kev hloov tsim nyog. Nruab cov khoom tshiab tom qab qhov kev txiav txim rov qab ntawm disassembly.
Reassembly: Thaum koj tau ntxuav lossis hloov cov khoom tsim nyog, ua raws li cov chaw tsim khoom cov lus qhia kom rov ua dua hydraulic pob zeb DTH rauj. Xyuas kom tseeb tias txhua qhov chaw tau nruj nruj thiab ua kom zoo.
Nco ntsoov, phau ntawv qhia dav dav no yuav tsis npog tag nrho cov kauj ruam tshwj xeeb thiab kev txiav txim siab rau koj qhov tshwj xeeb hydraulic pob zeb DTH rauj qauv. Nco ntsoov sab laj nrog cov chaw tsim khoom cov lus qhia thiab cov lus qhia rau cov txheej txheem disassembly kom raug thiab nyab xeeb tshaj plaws.
Specification
LEANOS
Technical Parameters Ntawm QL80 DTH Hammers
|
Bit Shank |
qw 80 |
|
Qhov Loj |
Φ{0}} hli |
|
Kev sib txuas xov |
API 4 1/2" Reg |
|
Ua Haujlwm Siab |
10-25Bar / 1-2.5Mpa |
|
Ceev Qhia |
20-45rpm |
|
Rub Force pom zoo |
19 KN |
|
Ntev |
1 471mm |
|
Qhov hnyav |
20 3 Kg |
Technical Parameters Ntawm QL80 DTH Bits
|
Txoj kab uas hla |
Gauge Khawm |
Pem hauv ntej khawm |
Qhov hnyav (KG) |
Tshooj Naj Npawb |
||||
|
mm |
Ntiv |
Lub ntsej muag |
Lub ntsej muag Convex |
Concave ntsej muag |
Hom ntsej muag |
|||
|
203 |
8 |
Φ18*10 |
Φ18*8 |
/ |
Φ16*5 |
Concave ntsej muag |
50.1 |
LN-QL80-203CC |
|
216 |
8 1/2 |
Φ18*10 |
Φ18*8 |
/ |
Φ16*6 |
Concave ntsej muag |
54.3 |
LN-QL80-216CC |
|
219 |
8 5/8 |
Φ18*10 |
Φ18*8 |
/ |
Φ16*6 |
Concave ntsej muag |
54.8 |
LN-QL80-219CC |
|
229 |
9 |
Φ18*12 |
Φ16*12 |
/ |
Φ16*7 |
Concave ntsej muag |
56.4 |
LN-QL80-229CC |
|
235 |
9 1/4 |
Φ18*12 |
Φ16*12 |
/ |
Φ16*7 |
Concave ntsej muag |
57.4 |
LN-QL80-235CC |
|
245 |
9 5/8 |
Φ19*12 |
Φ16*12 |
/ |
Φ16*8 |
Concave ntsej muag |
61.5 |
LN-QL80-245CC |
